Docker swarm on AWS with Ansible

Docker swarm on AWS with Ansible

Introduction

In this tutorial we'll be using Ansible to deploy a swarm cluster of 3 nodes on AWS.

Ansible

From the official documentation: Ansible is an IT automation tool. It can configure systems, deploy software, and orchestrate more advanced IT tasks such as continuous deployments or zero downtime rolling updates. Ansible’s main goals are simplicity and ease-of-use.

Ansible scripts are meant to reach a desired state and not to do a list of commands. If you wish to install curl on a server, Ansible will try to install curl ONLY IF it isn't installed yet.

This is an ansible task which download a file at a specific dest with specific user permissions. And in case the file already exists at the desired dest it will only replace the file if the content has changed.

- name: Fetching super_saiyan.py
  get_url:
    url: https://vegeta.world/super_saiyan.py
    dest: /my/path/super_saiyan.py
    owner: goku
    group: dragonballz
    mode: u=rwx,g=rwx,o=rx
    force: yes

When running an ansible script you'll see statuses such as ok or changed.

  • ok: nothing has been done, either the state is already met or we just set a fact.
  • changed: A command has been run to meet the desired state.

Docker swarm

Docker swarm is an orchestration service. Easy to use, it allows us to run our webapps at scale in production. You can see a summary list of its features here.

Some ressources from Docker official documentation on how to setup and use Docker swarm:

Setup and deploy ec2

For this project I'm using Python 3.7.4 and pip 19.0.3 and I'm running under Fedora 30. In this tutorial I assume:

  • You have an AWS account
  • You are familiar with ec2 and security groups from AWS
  • You have an IAM user with Programmatic access (AWS documention)

Dependencies

For this project we will need:

  • ansible
  • boto3
  • boto
  • botocore
# install dependencies
pip install ansible boto boto3 botocore

Here are the versions I have while I'm writing this.

[goku@vegeta tutorial]$ pip freeze | grep -E "boto3|boto|botocore|ansible"
ansible==2.8.5
boto==2.49.0
boto3==1.9.233
botocore==1.12.233

Export in your shell the AWS_SECRET_ACCESS_KEY, AWS_ACCESS_KEY_ID and AWS_REGION variables.

export AWS_ACCESS_KEY_ID='YOUR_AWS_API_KEY'
export AWS_SECRET_ACCESS_KEY='YOUR_AWS_API_SECRET_KEY'
# I'm currently on eu-west-1
export AWS_REGION='YOUR_AWS_REGION'

Let's test if everything is good. Create a file test_ec2_playbook.yml.

# test_ec2_playbook.yml
---
  # we don't connect to any servers, we use the AWS api
- hosts: localhost
  # Do not use ssh
  connection: local
  # Do not fetch variables from the server (there is none)
  gather_facts: False
  tasks:

    - name: "Gathering facts about all subnets and set fact: 'vpc_subnets_facts'"
      # AWS module to gather facts (variables) about subnets
      # https://docs.ansible.com/ansible/latest/modules/ec2_vpc_subnet_facts_module.html
      ec2_vpc_subnet_facts:
      # Create a fact "vpc_subnets_facts" from the result
      register: vpc_subnets_facts

    - name: "Printing 'vpc_subnets_facts' fact"
      # https://docs.ansible.com/ansible/latest/modules/debug_module.html
      debug:
        var: vpc_subnets_facts

Now run it. It will print all your subnets in the region.

ansible-playbook test_ec2_playbook.yml

If you have something like this, you're all good ! (if you see warnings, ignore them).

[...]
                "id": "subnet-e6bd14bc",
                "ipv6_cidr_block_association_set": [],
                "map_public_ip_on_launch": true,
                "owner_id": "859761867273",
                "state": "available",
                "subnet_arn": "arn:aws:ec2:eu-west-1:859761867273:subnet/subnet-e6bd14bc",
                "subnet_id": "subnet-e6bd14bc",
                "tags": {},
                "vpc_id": "vpc-453c0e23"
            },
            {
                "assign_ipv6_address_on_creation": false,
                "availability_zone": "eu-west-1c",
                "availability_zone_id": "euw1-az1",
                "available_ip_address_count": 4091,
                "cidr_block": "172.31.0.0/20",
                "default_for_az": true,
                "id": "subnet-94c0acf2",
                "ipv6_cidr_block_association_set": [],
                "map_public_ip_on_launch": true,
                "owner_id": "859761867273",
                "state": "available",
                "subnet_arn": "arn:aws:ec2:eu-west-1:859761867273:subnet/subnet-94c0acf2",
                "subnet_id": "subnet-94c0acf2",
                "tags": {},
                "vpc_id": "vpc-453c0e23"
            }
        ]
    }
}

PLAY RECAP *******************************************************************************************************
localhost                  : ok=2    changed=0    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0

Choose one subnet, write down your vpc_id and your subnet_id. Here they are "vpc_id": "vpc-453c0e23" and "subnet_id": "subnet-94c0acf2". If you have multiples, just pick one. We will need them later.

Setup architecture

Now we need to deploy our ec2 instances. In our script we will have 4 steps:

  • Create security_groups
  • Create a key pair (or use pre-existing one)
  • Find an AMI, in this tutorial we'll use Debian 9 (Stretch)
  • Create 3 ec2

Because we have 4 clear steps, we will write a file for each with their belonging tasks.

Create security groups

In AWS the security groups allow us to manage our ports. This is like a firewall around the server. It gives us features which make easier to manage our ports.

Create a folder tasks. Within it create a file named create_security_groups.yml.

Do not worry about "{{ VPC_ID }}" this is a variable and we will see later how to set a value for it.

# tasks/create_security_groups.yml
---
- name: create Swarm security groups
  # https://docs.ansible.com/ansible/latest/modules/ec2_group_module.html
  ec2_group:
    # The id of the security group
    name: swarm
    description: >-
      Allow swarm members to communicate between themselves,
      allow ssh and open ports for the example voting app.
    # The shown name
    tags:
      Name: swarm
    # Left as it is, we will set the variable later
    vpc_id: "{{ VPC_ID }}"
    rules:
      - proto: tcp
        from_port: 22
        to_port: 22
        rule_desc: "Allow ssh from everywhere."
        cidr_ip: 0.0.0.0/0
        cidr_ipv6: ::/0
      - proto: tcp
        from_port: 2377
        to_port: 2377
        group_name: swarm
        rule_desc: "Cluster management communications."
      - proto: tcp
        from_port: 7946
        to_port: 7946
        group_name: swarm
        rule_desc: "Communication among nodes."
      - proto: udp
        from_port: 7946
        to_port: 7946
        group_name: swarm
        rule_desc: "Communication among nodes."
      - proto: udp
        from_port: 4789
        to_port: 4789
        group_name: swarm
        rule_desc: "Overlay network traffic."
      - proto: tcp
        from_port: 8080
        to_port: 8080
        rule_desc: "Open ports for visualizer."
        cidr_ip: 0.0.0.0/0
        cidr_ipv6: ::/0
      - proto: tcp
        from_port: 5000
        to_port: 5001
        rule_desc: "Open ports for the vote and result apps."
        cidr_ip: 0.0.0.0/0
        cidr_ipv6: ::/0

Here we create our security_group in order to allow ssh, the ports for the service we will deploy and the ports needed by docker swarm but only limited to the members of the swarm.

Create key pair (or use pre-existing one)

In order to connect by ssh to our servers will we need a key pair.

# tasks/create_key_pair.yml
---
- name: "Trying to create a key pair"
  # https://docs.ansible.com/ansible/latest/modules/ec2_key_module.html
  ec2_key:
    name: "{{ KEY_PAIR_NAME }}"
    # If it exists do not overwrite
    force: false
  register: ansible_tutorial_private_key
  # Do not stop the playbook if it fails
  ignore_errors: yes

###############################################################
# ALL the code below will only run if the key pair is created #
# look at the "when" keys which controls when to run a task   #
###############################################################

- name: "Saving private key to {{ KEY_PAIR_LOCAL_PATH }}"
  # https://docs.ansible.com/ansible/latest/modules/copy_module.html
  copy:
    dest: "{{ KEY_PAIR_LOCAL_PATH }}"
    content: "{{ ansible_tutorial_private_key['key']['private_key'] }}"
    # Permissions for private key
    mode: '0600'
    # We do not want to overwrite a pre existing key
    force: no
  # We wish to run another task in case of error
  register: save_ansible_tutorial_private_key
  # ONLY run if "ansible_tutorial_private_key" was a success
  when: ansible_tutorial_private_key.changed == true
  # Do not stop the playbook if it fails
  ignore_errors: yes

- name: "Deleting {{ KEY_PAIR_NAME }} since it couldn't be saved"
  # https://docs.ansible.com/ansible/latest/modules/ec2_key_module.html
  ec2_key:
    name: "{{ KEY_PAIR_NAME }}"
    # Delete it
    state: absent
  # ONLY run if the previous tasks didn't write to the file
  when: ansible_tutorial_private_key.changed == true and save_ansible_tutorial_private_key.changed == false
  register: delete_key_pair

  # Stop the playbook and mark it as failed
  # https://docs.ansible.com/ansible/latest/modules/fail_module.html
- fail:
    msg: >
      The file {{ KEY_PAIR_LOCAL_PATH }} already exists but the
      key pair {{ KEY_PAIR_NAME }} doesn't exists on AWS.
      Change either the KEY_PAIR_NAME or the KEY_PAIR_LOCAL_PATH
  # ONLY run if the previous tasks didn't write to the file
  when: delete_key_pair.changed == true

When you create a key pair, AWS gives you the private key.
:warning: This is the only time you have access to it ! if you don't download it or loose it, the key pair becomes useless.

There is 4 ways those tasks can be triggered:

  • Neither the key pair nor the file exist. The script will create the key pair and create a file with its private key.
  • The key pair exists and the file too. Nothing is done since this is what we already want.
  • The key pair doesn't exist but the file does. We won't erase the file as we do not know what is contains, we will delete the key pair as we couldn't save the private key and raise an error asking the user to check his variables.
  • The key pair exists but the file doesn't. We will delete the key pair as we can't save the private key and raise an error asking the user to check his variables.

Find an AMI Debian 9 (Stretch)

# tasks/set_fact_ec2_ami.yml
---
- name: "set fact: Debian 9 (Stretch) AMI"
  # https://docs.ansible.com/ansible/latest/modules/ec2_ami_facts_module.html
  ec2_ami_facts:
    # see the full list of filtered elements:
    # https://eu-west-1.console.aws.amazon.com/ec2/home?region=eu-west-1#Images:visibility=public-images;search=379101102735,debian-stretch-hvm-x86_64-gp2-*;sort=desc:name
    owners: 379101102735
    filters:
      name: "debian-stretch-hvm-x86_64-gp2-*"
  register: debian_ami

- name: "set fact: get id from Debian 9 (Stretch) AMI"
  # https://docs.ansible.com/ansible/latest/modules/set_fact_module.html
  set_fact:
    # There is many debian AMI, let's take the first
    debian_ami_id: "{{ debian_ami.images[0].image_id }}"

Those tasks are straightforward. We look for a Debian 9 (Stretch) AMI made by Debian (379101102735), take the first and save the id in a fact.

Create ec2

We wish to create 3 ec2. 1 manager and 2 workers. We will iterate over a variable with the key loop.

# tasks/create_ec2.yml
---
- name: Creating ec2 instances
  # https://docs.ansible.com/ansible/latest/modules/ec2_module.html
  ec2:
    key_name: "{{ KEY_PAIR_NAME }}"
    # The security group
    group: "{{ item.group }}"
    instance_type: t2.nano
    image: "{{ debian_ami_id }}"
    # Wait until the ec2 is created (not running yet)
    wait: yes
    # Garanty only 1 ec2 with those count_tags
    exact_count: 1
    # Tags to identify uniquely an ec2
    count_tag:
      Name: "{{ item.tags.Name }}"
    # Other tags to attach to the ec2
    instance_tags: "{{ item.tags }}"
    # The subnet where to create the ec2
    vpc_subnet_id: "{{ SUBNET_ID }}"
    assign_public_ip: yes
  # Run this tasks for all elements in EC2_INSTANCES
  loop: "{{ EC2_INSTANCES }}"
  register: create_ec2

Notice the loop: "{{ EC2_INSTANCES }}" at the end of the task. It iterates the same module over the content of EC2_INSTANCES var.
Now let's create our EC2_INSTANCES variable in a file. Create a folder vars and within it a file named ec2.yml.

# vars/ec2.yml
---
- EC2_INSTANCES:
  - tags:
      Name: "swarm-manager"
      SwarmType: manager
      Swarm: yes
    group:
      - swarm
  - tags:
      Name: "swarm-worker-a"
      SwarmType: worker
      Swarm: yes
    group:
      - swarm
  - tags:
      Name: "swarm-worker-b"
      SwarmType: worker
      Swarm: yes
    group:
      - swarm

We store the tags and the security_group properties.

Create the playbook

In order to use our new tasks we will create a playbook which includes all 4 of them. Just like the playbook we wrote for the test. Create a create_ec2_playbook.yml file at the root of your project.

# create_ec2_playbook.yml
---
- hosts: localhost
  connection: local
  gather_facts: False
  vars:
    # The vpc_id and subnet_id choosen earlier
    VPC_ID: "YOUR_VPC_ID"
    SUBNET_ID: "YOUR_SUBNET_ID"
    # The key pair name on AWS
    KEY_PAIR_NAME: ansible_tutorial
    # The path to the private key on your machine
    KEY_PAIR_LOCAL_PATH: "~/.ssh/ansible_tutorial.pem"
  # Load variables from file
  vars_files:
    - vars/ec2.yml
  tasks:
      # Include all tasks within file
    - include_tasks: tasks/create_security_groups.yml
    - include_tasks: tasks/create_key_pair.yml
    - include_tasks: tasks/set_fact_ec2_ami.yml
    - include_tasks: tasks/create_ec2.yml

Please fill the VPC_ID and SUBNET_ID vars with the vpc_id and the subnet_id we have chosen after running ansible-playbook test_ec2_playbook.yml.

(optional) If you wish to use a pre-existing key_pair please change KEY_PAIR_NAME to its name on AWS and KEY_PAIR_LOCAL_PATH to the local path to the private key on your machine.

Your current project structure should look like this now.

[goku@vegeta tutorial]$ tree
.
├── create_ec2_playbook.yml
├── tasks
│   ├── create_ec2.yml
│   ├── create_key_pair.yml
│   ├── create_security_groups.yml
│   └── set_fact_ec2_ami.yml
├── test_ec2_playbook.yml
└── vars
    └── ec2.yml

2 directories, 7 files

Now run it !

ansible-playbook create_ec2_playbook.yml

Setup Docker swarm cluster

Now that we have our architecture running we wish to deploy a docker swarm cluster.

Inventory

In order to run our scripts against the desired servers Ansible uses an inventory. In short, an inventory is where you store your servers' ip addresses. You name them, create groups, setup variables by hosts / groups, it has a lot of features. It can be a folder or file.

But in our case, we create our servers dynamically, which means each time we deploy new servers, their ip address changes. So we will use the AWS ec2 plugin which creates dynamic hosts.

If you wish to know more about inventories you check the documentation here.

Ansible and Dynamic Amazon EC2 Inventory Management

Create an inventory folder at the project root. Within, we will create two files:

  • ec2.py the AWS core plugin, you can download it here
  • ec2.ini the configuration file, I've adjusted one for the tutorial here or you can download the default one here

Make ec2.py executable to avoid any issues with ansible.

chmod +x inventory/ec2.py

Test if the plugin is working as desired. It may take a few moment to get the result as the plugin is doing multiples requests on AWS

inventory/ec2.py --list

You should see something like this:

[...]
       "ec2_tag_Name": "swarm-worker-b",
        "ec2_tag_Swarm": "True",
        "ec2_tag_SwarmType": "worker",
        "ec2_virtualization_type": "hvm",
        "ec2_vpc_id": "vpc-453c0e23"
      }
    }
  },
  "ec2": [
    "34.254.184.38",
    "34.244.247.140",
    "34.255.136.188"
  ],
  "tag_Name_swarm_manager": [
    "34.254.184.38"
  ],
  "tag_Name_swarm_worker_a": [
    "34.244.247.140"
  ],
  "tag_Name_swarm_worker_b": [
    "34.255.136.188"
  ],
  "tag_SwarmType_manager": [
    "34.254.184.38"
  ],
  "tag_SwarmType_worker": [
    "34.244.247.140",
    "34.255.136.188"
  ],
  "tag_Swarm_True": [
    "34.254.184.38",
    "34.244.247.140",
    "34.255.136.188"
  ]
}

Here you can see all the different servers, groups and variables available.

if you have any troubles or wish to know more about it, here is the documentation.

Project setup

Now create an ansible.cfg file at the root of our project to specify a few default options.

# ansible.cfg
[defaults]
# (optional) the host check keys from ssh
# is enabled by default and may causes
# issues while following the tutorial
host_key_checking=false

# Tells ansible where the inventory files are
inventory=inventory/

Here we disable host_key_checking to remove constraints from this tutorial as it may causes issues (it is security related). We also define where the inventory files are.

We have set the KEY_PAIR_NAME and KEY_PAIR_LOCAL_PATH variables in the create_ec2_playbook.yml playbook. But we will need them in our next playbooks. So we'll move them in a variable file.

Create a folder group_vars and create a file all.yml in it. Move your KEY_PAIR_NAME and KEY_PAIR_LOCAL_PATH variables in it.

# group_vars/all.yml
---
KEY_PAIR_NAME: ansible_tutorial
KEY_PAIR_LOCAL_PATH: "~/.ssh/ansible_tutorial.pem"

All files within groups_vars are automatically read by Ansible depending on the current group or host currently running. Here all.yml will be used for all hosts or groups. This way we ensure those variables are accessible from everywhere.

By default our ec2 can be accessed with the user admin (this is related to the AMI we're using). To specify Ansible which user and which private key to use we will create an other file ec2.yml in group_vars. All dynamic hosts from the AWS ec2 plugin are part of the ec2 group.

# group_vars/ec2.yml
---
ansible_user: admin
ansible_ssh_private_key_file: "{{ KEY_PAIR_LOCAL_PATH }}"

Those variables will be used ONLY by the hosts that belonged to the ec2 group.

To check everything is setup correctly we'll write a little playbook. Note this test will work only if your servers are online and running.

# test_dynamic_aws_host_playbook.yml
---
  # Run the playbook for all ec2 instances sharing the tag Swarm=True
- hosts: "tag_Swarm_True"
  tasks:
    - name: "Ping the ec2 with Swarm=True tag"
      # https://docs.ansible.com/ansible/latest/modules/ping_module.html
      ping:

Our current project structure should look like this:

[goku@vegeta tutorial]$ tree
.
├── ansible.cfg
├── create_ec2_playbook.yml
├── group_vars
│   ├── all.yml
│   └── ec2.yml
├── inventory
│   ├── ec2.ini
│   └── ec2.py
├── tasks
│   ├── create_ec2.yml
│   ├── create_key_pair.yml
│   ├── create_security_groups.yml
│   └── set_fact_ec2_ami.yml
├── test_dynamic_aws_host_playbook.yml
├── test_ec2_playbook.yml
└── vars
    └── ec2.yml

4 directories, 13 files

Run it (may take a few moments because of the AWS dynamic host)

ansible-playbook test_dynamic_aws_host_playbook.yml

If you see something like this everything is working as expected :ok_hand:

PLAY [tag_Swarm_True] *********************************************************************************************************************

TASK [Gathering Facts] ********************************************************************************************************************
ok: [34.240.55.248]
ok: [34.242.96.200]
ok: [18.203.135.17]

TASK [Ping the ec2 with Swarm=True tag] ***************************************************************************************************
ok: [18.203.135.17]
ok: [34.240.55.248]
ok: [34.242.96.200]

PLAY RECAP ********************************************************************************************************************************
18.203.135.17              : ok=2    changed=0    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0
34.240.55.248              : ok=2    changed=0    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0
34.242.96.200              : ok=2    changed=0    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0

Something is wrong if you see something like this :collision:

PLAY [tag_Swarm_true] *********************************************************************************************************************
skipping: no hosts matched

It means either your ec2 aren't online and running or they do not have the tag Swarm=True (case sensitive).

Install Docker

We will install Docker on a Debian 9 (Stretch). I've followed the instruction from the official Docker documentation and wrote the tasks.

# tasks/install_docker.yml
---
- name: Ensure dependencies are installed
  # https://docs.ansible.com/ansible/latest/modules/apt_module.html
  apt:
    name:
      - apt-transport-https
      - ca-certificates
      - curl
      - gnupg-agent
      - software-properties-common
    state: present

- name: Add Docker apt key
  # https://docs.ansible.com/ansible/latest/modules/apt_key_module.html
  apt_key:
    url: https://download.docker.com/linux/debian/gpg
    id: 9DC858229FC7DD38854AE2D88D81803C0EBFCD88
    state: present
  register: add_repository_key

- name: Get debian version
  # https://docs.ansible.com/ansible/latest/modules/command_module.html
  command: lsb_release -cs
  register: debian_version_name

- name: Add Docker repository
  # https://docs.ansible.com/ansible/latest/modules/apt_repository_module.html
  apt_repository:
    repo: "deb [arch=amd64] https://download.docker.com/linux/debian {{ debian_version_name.stdout }} stable"
    state: present
    update_cache: true

- name: Ensure docker is installed
  # https://docs.ansible.com/ansible/latest/modules/apt_module.html
  apt:
    name:
      - docker-ce
      - docker-ce-cli
      - containerd.io
    state: present
    update_cache: true

- name: Ensure Docker is started and enabled at boot
  # https://docs.ansible.com/ansible/latest/modules/service_module.html
  service:
    name: docker
    state: started
    enabled: true

- name: Ensure handlers are notified now to avoid firewall conflicts
  # https://docs.ansible.com/ansible/latest/modules/meta_module.html
  meta: flush_handlers

- name: "Ensure the user {{ ansible_user }} is part of the docker group"
  # https://docs.ansible.com/ansible/latest/modules/user_module.html
  user:
    name: "{{ ansible_user }}"
    groups: docker
    append: yes

#########################################################################################
#               We install the docker python module as it is recommended                #
#                   for the docker_swarm module that we will use later                  #
# https://docs.ansible.com/ansible/latest/modules/docker_swarm_module.html#requirements #
#########################################################################################

- name: Ensure docker python module and jsondiff are installed
  # https://docs.ansible.com/ansible/latest/modules/pip_module.html
  pip:
    name:
      - docker
      # jsondiff and pyyaml are needed by the docker_stack module
      - jsondiff
      - pyyaml
  register: pip_install_docker
  ignore_errors: yes

- name: Fetching pip
  # https://docs.ansible.com/ansible/latest/modules/get_url_module.html
  get_url:
    url: https://bootstrap.pypa.io/get-pip.py
    dest: "/home/{{ ansible_user }}/get-pip.py"
    mode: u=rwx,g=rwx,o=rx
  when: pip_install_docker is failed

- name: Installing pip
  # https://docs.ansible.com/ansible/latest/modules/command_module.html
  command: "python /home/{{ ansible_user }}/get-pip.py"
  when: pip_install_docker is failed

- name: Installing docker python module and jsondiff
  # https://docs.ansible.com/ansible/latest/modules/pip_module.html
  pip:
    name:
      - docker
      # jsondiff and pyyaml are needed by the docker_stack module
      - jsondiff
      - pyyaml
  when: pip_install_docker is failed

Init Docker Swarm

Docker is installed, we can now init the Swarm on a manager node. Docker Swarm is easy to setup:

  • Init the Swarm on a server and save the join token worker and join token manager
  • On the other managers make them join the Swarm thanks to the join token manager
  • On the workers use the join token worker

We will ask Ansible to use the first Swarm manager node to init the swarm. We could specify a specific server but I prefer to just take the first one. In a large swarm cluster you have multiple manager and worker nodes and by taking the first, our script will still be working in case the very server we specified is down for example.

# tasks/init_swarm.yml
---
- name: Setting up Swarm
  # Similar to a Try/Except
  # https://docs.ansible.com/ansible/latest/user_guide/playbooks_blocks.html#blocks-error-handling
  block:
    - name: Initiating the swarm with default parameters
      # https://docs.ansible.com/ansible/latest/modules/docker_swarm_module.html
      docker_swarm:
        state: present
      register: init_swarm

    - name: "set fact: join token worker"
      set_fact:
        join_token_worker: "{{ init_swarm.swarm_facts.JoinTokens.Worker }}"

    - name: "set fact: join token manager"
      set_fact:
        join_token_manager: "{{ init_swarm.swarm_facts.JoinTokens.Manager }}"

  rescue:
    - name: Getting join manager token from existing Swarm
      # https://docs.ansible.com/ansible/latest/modules/command_module.html
      command: docker swarm join-token manager -q
      register: join_token_manager_command

    - name: Getting join worker token from existing Swarm
      # https://docs.ansible.com/ansible/latest/modules/command_module.html
      command: docker swarm join-token worker -q
      register: join_token_worker_command

    - name: "set fact: join_token_manager"
      set_fact:
        join_token_manager: "{{ join_token_manager_command['stdout'] }}"

    - name: "set fact: join_token_worker"
      set_fact:
        join_token_worker: "{{ join_token_worker_command['stdout'] }}"

Join the worker nodes

Our Swarm is initiated, from the worker nodes, use the join token worker and specify a manager node's address to make them part of the Swarm.

# tasks/join_worker_node.yml
---
- name: "set fact: first Swarm manager host"
  set_fact:
    first_swarm_manager_host: "{{ groups['tag_SwarmType_manager'][0] }}"

- name: 'set fact: list remote_addrs'
  set_fact:
    # Create a list of all managers' private ip addresse
    list_remote_addrs: >-
      {{ list_remote_addrs | default([]) }} + [ '{{ item }}:2377' ]
  loop: >-
    {{ groups['tag_SwarmType_manager'] | map('extract', hostvars, 'ec2_private_ip_address') | list }}

- name: Joining worker to the swarm
  # https://docs.ansible.com/ansible/latest/modules/docker_swarm_module.html
  docker_swarm:
    state: join
    timeout: 60
    # Using PRIVATE IP ADDRESS as they are in the same VPC
    advertise_addr: >-
      {{ ec2_private_ip_address }}:2377
    # hostvars contains all variables related to a host
    # https://docs.ansible.com/ansible/latest/user_guide/playbooks_variables.html#accessing-information-about-other-hosts-with-magic-variables
    join_token: >-
      {{ hostvars[first_swarm_manager_host].join_token_worker }}
    # Using PRIVATE IP ADDRESS as they are in the same VPC
    remote_addrs: "{{ list_remote_addrs }}"

Here we use the hostvars. The hostvars allows us to access variables from other hosts, here we take two variables:

  • join_token_worker the token given by the first swarm manager who allows us to join the Swarm
  • ec2_private_ip_address the private ip address. Since our servers share the same subnet they can communicate by private ip address. And our security groups ONLY opens the Docker ports to the servers member of the swarm security group and this implies communicating by private ip address.
# deploy_swarm_playbook.yml
---
  # Take the first ec2 whose tag SwarmType is equal to "manager"
- hosts: tag_SwarmType_manager[0]
  # Use sudo for all tasks
  become: yes
  tasks:
    - include_tasks: tasks/install_docker.yml
    - include_tasks: tasks/init_swarm.yml

- hosts: tag_SwarmType_worker
  # Use sudo for all tasks
  become: yes
  tasks:
    - include_tasks: tasks/install_docker.yml
    - include_tasks: tasks/join_worker_node.yml

Deploy the cluster :rocket: (if it is unreachable wait a bit until the ec2 get to the running state).

ansible-playbook deploy_swarm_playbook.yml

Check cluster

Our Swarm cluser should be ready. To check it let's connect to it by ssh.

(Optional) If you're too lazy to check your swarm manager node's ip upper or from the aws console you can run this command:

[goku@vegeta tutorial]$ inventory/ec2.py --list | grep tag_SwarmType_manager -A 2

# output
"tag_SwarmType_manager": [
    "34.242.96.200" # <- here
  ],
# ajust ~/.ssh/ansible_tutorial.pem if needed
[goku@vegeta tutorial]$ ssh -i ~/.ssh/ansible_tutorial.pem admin@34.242.96.200

admin@ip-172-31-8-57:~$ docker node ls

# Tada ! Your swarm is running
ID                            HOSTNAME            STATUS              AVAILABILITY        MANAGER STATUS      ENGINE VERSION
scqe6rb9h0016g8wmeohfkv32     ip-172-31-5-233     Ready               Active                                  19.03.2
yhokk5ae4l22ssmpkslqbz4p7 *   ip-172-31-8-57      Ready               Active              Leader              19.03.2
td9vjq0myikqhr7dzwky8enut     ip-172-31-15-91     Ready               Active                                  19.03.2

Deploy service

We have our swarm cluster running. It is time to deploy our first service.

I'm using a stack file from the repo https://github.com/dockersamples. Their projects are complex enough for development and testing. We will be using the docker-stack.yml from the example-voting-app. It uses redis, postgres, an app in python, an app in nodejs, a worker in .NET and even a visualizer !

I've created a example-voting-app folder and a docker-compose.yml file in it.

# example-voting-app/docker-compose.yml
version: "3"
services:

  redis:
    image: redis:alpine
    networks:
      - frontend
    deploy:
      replicas: 1
      update_config:
        parallelism: 2
        delay: 10s
      restart_policy:
        condition: on-failure
  db:
    image: postgres:9.4
    volumes:
      - db-data:/var/lib/postgresql/data
    networks:
      - backend
    deploy:
      placement:
        constraints: [node.role == manager]
  vote:
    image: dockersamples/examplevotingapp_vote:before
    ports:
      - 5000:80
    networks:
      - frontend
    depends_on:
      - redis
    deploy:
      replicas: 2
      update_config:
        parallelism: 2
      restart_policy:
        condition: on-failure
  result:
    image: dockersamples/examplevotingapp_result:before
    ports:
      - 5001:80
    networks:
      - backend
    depends_on:
      - db
    deploy:
      replicas: 1
      update_config:
        parallelism: 2
        delay: 10s
      restart_policy:
        condition: on-failure

  worker:
    image: dockersamples/examplevotingapp_worker
    networks:
      - frontend
      - backend
    depends_on:
      - db
      - redis
    deploy:
      mode: replicated
      replicas: 1
      labels: [APP=VOTING]
      restart_policy:
        condition: on-failure
        delay: 10s
        max_attempts: 3
        window: 120s
      placement:
        constraints: [node.role == manager]

  visualizer:
    image: dockersamples/visualizer:stable
    ports:
      - "8080:8080"
    stop_grace_period: 1m30s
    volumes:
      - "/var/run/docker.sock:/var/run/docker.sock"
    deploy:
      placement:
        constraints: [node.role == manager]

networks:
  frontend:
  backend:

volumes:
  db-data:

Create a new task file deploy_example_voting_app_stack.yml under tasks:

# tasks/deploy_example_voting_app_stack.yml
---
- name: Copying example voting app's docker-compose.yml file on the server
  # https://docs.ansible.com/ansible/latest/modules/copy_module.html
  copy:
    src: "example-voting-app/docker-compose.yml"
    dest: "/home/{{ ansible_user }}/docker-compose.yml"
    owner: "{{ ansible_user }}"
    group: "{{ ansible_user }}"
    mode: u=rw,g=rw,o=r
    force: yes

- name: Deploying example voting app's stack
  # https://docs.ansible.com/ansible/latest/modules/docker_stack_module.html
  docker_stack:
    state: present
    name: "{{ STACK_NAME | default('example_voting_app') }}"
    compose:
      - "/home/{{ ansible_user }}/docker-compose.yml"

The playbook deploy_stack_playbook.yml

# deploy_stack_playbook.yml
---
- hosts: tag_SwarmType_manager[0]
  tasks:
    - include_tasks: tasks/deploy_example_voting_app_stack.yml

Deploy ! This is the very last step. :rocket:


ansible-playbook deploy_stack_playbook.yml

Once it's done, you may need to wait 10~20 seconds while waiting for all services to get deployed.

Now you can access your apps from any nodes :tada: !

(Optional) If you wish the list of all your servers' public IP address you can run this.


inventory/ec2.py --list | grep tag_Swarm_True -A 3

Pick any one of them, doesn't matter if it is a manager or a worker the mode routing mesh does it all for you. We have those apps running:

  • vote - port: 5000
  • result - port: 5001
  • visualizer - port: 8080

On any servers you can access vote, result and visualizer !

Clean the tutorial

Now that we have accomplished what we wanted, let's clean up our servers and security_groups. Here are the tasks and playbook to delete our ec2 and security_group.

Remove the ec2.

---
# tasks/remove_ec2.yml
- name: "set fact: Swarm ec2 instances"
  # https://docs.ansible.com/ansible/latest/modules/ec2_instance_facts_module.html
  ec2_instance_facts:
    filters:
      "tag:Swarm": "True"
  register: swarm_ec2

- name: "Removing ec2 instances"
  # https://docs.ansible.com/ansible/latest/modules/ec2_module.html
  ec2:
    instance_ids: "{{ item.instance_id }}"
    wait: yes
    state: absent
  loop: "{{ swarm_ec2.instances }}"
  when: swarm_ec2.instances != []

Remove the security_group.

---
# tasks/remove_security_groups.yml
- name: "set fact: security_groups"
  # https://docs.ansible.com/ansible/latest/modules/ec2_group_facts_module.html
  ec2_group_facts:
    filters:
      group-name:
        - swarm
  register: security_groups

- name: "Removing security groups"
  # https://docs.ansible.com/ansible/latest/modules/ec2_group_module.html
  ec2_group:
    group_id: "{{ item.group_id }}"
    state: absent
  loop: "{{ security_groups.security_groups }}"

The playbook.

# remove_ec2_playbook.yml
---
- hosts: localhost
  connection: local
  gather_facts: False
  tasks:
    - include_tasks: tasks/remove_ec2.yml
    - include_tasks: tasks/remove_security_groups.yml

Clean it. You wouldn't want to forget you have 3 servers running somewhere on AWS.


ansible-playbook remove_ec2_playbook.yaml

Source project

You can find the final version of this project on my repo

Last thoughts 😊

There is many ways to achieve this. This article and this project were written for sharing knowledge and not for production level architecture. If you're looking for more complex projects you can check Ansible galaxy for some roles. In short roles are reusable set of tasks meant to be used in other playbooks. I hope this tutorial will help you understand how Ansible works. This is a very powerful tool that is self documented by nature. Ideal to build your architecture and keep a written document on how it works.

Ansible galaxy

Ansible galaxy is a hub for finding and sharing Ansible content. You can find Docker Swarm roles/examples here.

Docker swarm

At Seelk we use Docker swarm for our architecture. It provides us a resilient and stable architecture which is also easy to maintain.
If you're interested to know more about Docker swarm you can find a very good tutorial on their website.

Copyright 2020 © All rights reserved

Seelk New York

5th Avenue

001 938872 0238

Seelk Paris

7 - 11 Boulevard Haussman

0033 1873 378273
